Dual Camera
|
PTZ optical zoom lens
<ul>
<li>Image sensor: Sony 4K EXMOR, crystal clear in any lighting</li>
<li>Frame rates: (16:9) 4K 30fps; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps</li>
<li>24X Zoom*: 12X optical; 2X digital zoom</li>
<li>Wide field of view: DFOV 85°; HFOV 76°; VFOV 46°</li>
<li>Lens focal length: 3.9mm (wide) ~ 47.3mm (tele)</li>
<li>Lens F#: 1.8 (wide) ~ 2.8 (tele)</li>
<li>AE, white balance: auto, manual override via Room Management (PTZApp 2)</li>
<li>Minimum focus distance: 1.5m</li>
<li>Motorized Pan & tilt: Pan: ±170°;Tilt: +90° (up) -30° (down)</li>
<li>Preset number: 10 via IR remote, 128 via RS232</li>
</ul>
<p><strong>Secondary fixed lens (AI lens)</strong></p>
<ul>
<li>Image sensor: Sony 4K EXMOR</li>
<li>Frame rates and resolution set according to PTZ lens settings</li>
<li>Wide field of view: DFOV 95°; HFOV 82°; VFOV 52°</li>
</ul>
</td>
</tr>
<tr>
<td style="width:118.25pt">
<p>Innovative features</p>
</td>
<td style="width:321.45pt">
<ul>
<li>Dynamic auto framing: secondary AI lens detects all participants, new participants trigger PTZ lens to dynamically frame all participants.</li>
<li>Preset framing tracks both preset area and speaker*</li>
<li>Simultaneous 3-way output: USB, HDMI and IP connections</li>
<li>Gesture control provides intuitive camera controls</li>
<li>HDMI Picture in Picture (PIP) function</li>
<li>Smart Gallery** function offers great visibility for individual participant in the meeting room</li>
<li>Cableless access to meetings: Get rid of USB cable connections with AVer virtual USB streaming technology** (One RJ45 cable transfers IP streaming to USB.)</li>
<li>Audio tracking support: Integration with AVer FONE700 & 3rd party ceiling microphone (Shure/Sennheiser) via AVer Preset Link ** function.</li>
<li> </li>
</ul>
</td>
</tr>
<tr>
<td style="width:118.25pt">
<p>Connectivity</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>USB type-B 3.1 connector, backward compatible with USB 2.0</li>
<li>12V/2A DC jack power adapter</li>
<li>Type Non-B Mini DIN 9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)</li>
<li>IP (RJ45)</li>
<li>HDMI</li>
</ul>
</td>
</tr>
<tr>
<td style="width:118.25pt">
<p>HDMI & PoE</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>HDMI 1.3: 1080p 30fps/ 60fps</li>
<li>PoE+: 802.3at</li>
</ul>
</td>
</tr>
<tr>
<td style="height:9.25pt; width:118.25pt">
<p>Video Format</p>
</td>
<td style="height:9.25pt; vertical-align:top; width:321.45pt">
<ul>
<li>YUV, YUY2, MJPEG</li>
<li>Network video compression format: H.264, H.265</li>
<li>Network protocol: RTSP, RTMP</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>USB</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>3.1 Gen 1, backward compatible with USB 2.0</li>
<li>UVC 1.1 (USB video), UVC1.5*</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Control</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>IR remote control</li>
<li>VISCA/pelco P/pelco D via RS232 (128 preset points via VISCA command)</li>
<li>Remote side: VISCA over IP, IP (RJ45)</li>
<li>UVC plug and play</li>
<li>WebUI: Browser IP access via Chrome. (Not support IE)</li>
<li>OSD setting: HDMI out to TV monitor</li>
<li>Room Management (PTZApp 2)</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Power Supply</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>AC 100V–240V, 50/60 Hz; Consumption: 12V, 2A</li>
<li>PoE+: 802.3 at</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Software Tools</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li><strong>Room Management (PTZApp 2) : </strong>Supports Windows® 7 or later, macOS® 11.6 or later</li>
<li><strong>Enterprise Management (PTZ Management) : </strong>Supports Windows® 10 or later</li>
<li><strong>Cloud Management : </strong>Supports Windows® 7 or later, macOS® 10 or later</li>
<li><strong>EZManager 2 : </strong>Supports Windows® 7 or later</li>
<li><strong>EZLive : </strong>Supports Windows® 7 or later</li>
</ul>
</td>
</tr>
<tr>
<td style="height:81.7pt; vertical-align:top; width:118.25pt">
<p>Environment Data</p>
</td>
<td style="height:81.7pt; vertical-align:top; width:321.45pt">
<ul>
<li>Operation temperature: 0 to 40°C</li>
<li>Operation humidity: 20% to 80%</li>
<li>Storage temperature: -20 to 60°C</li>
<li>Storage humidity: 20% to 80%</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Dimensions</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Package dimensions: 253(L)*253(W)*271(H) mm</li>
<li>Package weight: 4.8KG</li>
<li>Camera: 170.8 (L) X 190.5 (H) X 173 (D) mm/ 2.1kg</li>
<li>Remote control: 200 x 50 x 21 mm/90g</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Package Contents</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>CAM550 unit</li>
<li>Power adapter (10 ft/3 m)</li>
<li>USB 3.1 type-B to type-A cable (3m)</li>
<li>Remote control</li>
<li>Mini DIN9 to mini DIN8 RS232 adapter cable</li>
<li>HDMI cable (3 m)</li>
<li>Wall mount bracket and screws</li>
<li>Tripod screw</li>
<li>Drill paper</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Optional Accessories</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Mini DIN8 to D-Sub9 cable</li>
<li>Ceiling mount*</li>
<li>Foldable TV mount</li>
<li>USB2.0 type-B to type-A cable (5 m)</li>
<li>USB 3.1 Extension Cable (10 m/20 m/30 m)</li>
<li>1-Port POE+ Injector</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Security and Mount</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Kensington lock</li>
<li>1/4' tripod mounting screw</li>
<li>Camera wall-mount bracket included</li>
<li>Optional foldable TV mount</li>
<li>Optional ceiling mount</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>System Requirements</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Windows 7/10/11</li>
<li>Mac OS X 10.14 or later</li>
<li>Chromebox 3 version 94.0.4606.114 or later</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Hardware Specs</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>3.2 GHz Intel® Core™ i5-4460 processor</li>
<li>4 GB RAM or more</li>
<li>USB 3.1 port, backward compatible with USB 2.0</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Compatible Applications</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit</li>
</ul>
</td>
</tr>
</tbody>
|
