Camera
|
- 4K dual-lens technology delivers a wide 113° field of view (FOV) with 18X zoom
- 4K 3X varifocal lens: FOV (D/H/V) 92°/81°/50°
- 4K fixed lens: FOV (D/H/V) 113°/105°/71°
- Sony 4K sensor: ultra-crystal-clear image in any lighting
- Frame rate: (16:9) 1280 x 720 at 60, 30, 15fps; 4K, 3264 x 1836, 2560 x 1440, 1920 x 1080, 1600 x 900, 960 x 540, 848 x 480, 800 x 448, 640 x 360 at 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 30, 15fps
- Adjustable audio fence: Freedom to define wide/ medium/ narrow view fence
- SmartFrame & SmartSpeaker: Automatic tracking and FOV adjustment to fit all participants and focus on the speaker
- Presentation mode: Voice-triggered tracking on both defined areas and speakers
- Smart gallery* function enhances visibility
- Gesture control for intuitive camera control
- WDR, white balance and more image settings via Room Management (PTZApp 2)
- Minimum focus distance: 100 cm
- People counting API: Enterprises and third-party software providers can obtain people-counting and meeting-interval data tor better understand meeting space usage
|
|
Motorized Pan and Tilt Movement
|
- Pan: Total horizontal viewing area 165°
- Tilt: Total vertical viewing area 101°
- 10 camera presets
|
|
Audio
|
- 14-element beamforming microphone array
- 10 meters pickup range*
- Volume up to 96 dB SPL at 1/2 m
- Echo cancellation
- AI noise suppression
|
|
HDMI
|
- One cable solution: Built-in USB 3.1 (Gen 1) to HDMI adapter
- 4K HDMI output to TV*
|
|
Connectivity
|
- 12V/5A power adapter
- Mini DIN 6 for RS-232 connection
- USB 3.1 type B port, backward compatible with USB 2.0
- HDMI out connection (USB to HDMI adapter)
- Phone-in (1Vrms input)/speaker-out for HA system*
- RJ45 ports x2: one for Ethernet, one for audio expansion speakerphone / microphone
- USB 2.0 type A x3: Wireless connection**, USB to support IFP USB touch back, and expansion port
|
|
Video Format
|
- YUV, YUY2, M-JPEG
- Network video compression formats: H.264
- Network protocols: RTSP, RTMP
|
|
USB
|
- 3.1 Gen 1, backward compatible with USB 2.0
- UVC 1.1 (USB Video), UAC 1.0 (USB Audio)
|
|
Control
|
- IR remote control
- WebUI: IP access via Chrome browser (Chrome 76.x or later; Internet Explorer not supported)
- VISCA/pelco P/pelco D via RS-232/VISCA over IP
- UVC/UAC plug-and-play
- Room Management (PTZApp 2)
|
|
Mount and Security
|
- Wall-mount bracket (included)
- TV VESA mount kit (optional)
- Kensington security lock
|
|
System Requirements
|
Software
<ul>
<li>Windows® 7/10/11</li>
<li>Mac OS X 10.14 or later</li>
<li>Chromebox 3 version 94.0.4606.114 or later</li>
</ul>
<p><strong>Hardware</strong></p>
<ul>
<li>3.2 GHz Intel® Core™ i5-4460 processor</li>
<li>4 GB RAM or more</li>
<li>USB 3.1 port, backward compatible with USB 2.0</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Power Supply</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>AC 100V–240V, 50/60 Hz</li>
<li>Consumption: 12V/4.5A</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Software Tools</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li><strong>Room Management (PTZApp 2) : </strong>Supports Windows® 7 or later, macOS® 11.6 or later</li>
<li><strong>Enterprise Management (PTZ Management) : </strong>Supports Windows® 10 or later</li>
<li><strong>EZManager 2 : </strong>Supports Windows® 7 or later</li>
<li><strong>EZLive : </strong>Supports Windows® 7 or later, macOS® 10.13 or later</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Environmental Data</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Operation temperature: 0°C ~ 40°C</li>
<li>Operation humidity: 20% ~ 80%</li>
<li>Storage temperature: -20°C ~ 60°C</li>
<li>Storage humidity: 20% ~ 80%</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Dimensions</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Package dimensions: 872 mm (L) x 197 mm (W) x 260 mm (H)</li>
<li>Package weight: 7.4 kg</li>
<li>Camera: 791 mm (L) x 128 mm (W) x 126 mm (H)/3.3 kg</li>
<li>Remote control: 150 mm (L) x 42 mm (W) x 19 mm (H)/50 g</li>
</ul>
</td>
</tr>
<tr>
<td style="vertical-align:top; width:118.25pt">
<p>Compatible Applications</p>
</td>
<td style="vertical-align:top; width:321.45pt">
<ul>
<li>Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit</li>
</ul>
</td>
</tr>
</tbody>
|
